頂管施工的地表沉降數值分析和頂力計算
[1]陳楊,馬保松,曾聰.頂管施工的地表沉降數值分析和頂力計算[J].中國給水排水,2020,36(20):27-31.
CHEN Yang,MA Bao-song,ZENG Cong.Numerical Analysis of Surface Settlement and Calculation of Jacking Force for Pipejacking Construction[J].China Water & Wastewater,2020,36(20):27-31.
點擊復制
CHEN Yang,MA Bao-song,ZENG Cong.Numerical Analysis of Surface Settlement and Calculation of Jacking Force for Pipejacking Construction[J].China Water & Wastewater,2020,36(20):27-31.
頂管施工的地表沉降數值分析和頂力計算
中國給水排水[ISSN:1000-4062/CN:12-1073/TU] 卷: 第36卷 期數: 2020年第20期 頁碼: 27-31 欄目: 出版日期: 2020-10-17
- Title:
- Numerical Analysis of Surface Settlement and Calculation of Jacking Force for Pipejacking Construction
- 摘要:
- 閩江北水南調(平潭引水)工程管道施工將采用非開挖頂管法施工，穿越地層主要有淤泥質土層、中砂層及中風化凝灰熔巖。頂管頂力計算得到了4個頂進段的頂力預測值。根據已有的工作成果，將頂管施工對周圍土體產生的擾動情況進行了分析總結。通過模擬頂管地表沉降并分析規(guī)律，將模擬結果與Peck公式計算結果進行對比，驗證了所建模型得到的地層沉降的基本趨勢，分析了不同橫斷面沉降幅度變化的可能原因，為該工程施工提供了設計參考。
- Abstract:
- Trenchless pipe jacking technology is proposed to be used in the pipeline construction of Minjiang River North to South Water Diversion Project（Pingtan Water Diversion Project）, and the strata mainly includes silt soil layer, middle sand layer and middle weathering lava. The predicted values of jacking force of four jacking sections are obtained by calculation. Based on the previous results, the perturbation of the surrounding soil is investigated. By simulating the surface settlement of pipe jacking and analyzing the patterns, the simulation results are compared with the calculation results from the Peck formula, the basic trend of ground settlement obtained by the established model is verified. And the possible reasons for the change of settlement amplitude of different cross sections are discussed, which provides preliminary supports for the engineering construction design.
