水泥砂漿噴涂法修復鋼筋混凝土管道結構性能
- Title:
- Structural Performance of Reinforced Concrete Pipe Repaired by Cement Mortar Spraying Method
- 關鍵詞:
- 地下管道; 非開挖修復; 三邊荷載試驗; 有限元模擬
- 摘要:
- 水泥砂漿噴涂法非開挖修復技術能夠提高管道力學性能，目前在國內應用廣泛。為深入探究砂漿內襯修復技術對管道的修復效果和機理，對一根直徑1 m、垂直變形為14.7％、砂漿內襯層厚度為50 mm的修復鋼筋混凝土管道進行裂紋三邊荷載試驗，得到了修復后管道裂縫萌生和承載能力變化規律。根據試驗結果建立有限元模型，分析了砂漿噴涂厚度、原管變形程度、內襯層加筋對修復效果的影響。研究結果表明，內襯層厚度增加可以提高修復結構的承載力，并在原管破損程度較小時修復效果較好；內襯層加筋可提升修復管道的力學性能，配筋率增加可提高修復承載能力，鋼筋加固位置越靠近內襯管內表面，修復結構的抗裂強度就越高，極限承載力越低。
- Abstract:
- The trenchless rehabilitation technology of cement mortar spraying can improve the mechanical properties of pipelines, and currently is widely used in China. In order to further explore the effect and mechanism of mortar lining repair technology on the pipeline, a three-edge bearing test was carried out on a repaired concrete pipeline of diameter 1 m, vertical deformation 14.7%, and lining thickness 50 mm.The law of pipeline crack initiation and bearing capacity variation after repair was obtained. Based on the test results, a finite element model was established to analyze the influence of mortar spraying thickness, original pipe deformation degree, and reinforced inner lining on the repair effect. The research results show that the increase of inner lining thickness can improve the bearing capacity of the repaired structure, and the repair effect is better when the original pipe is less damaged; the reinforced inner lining can improve the mechanical properties of the repaired pipeline and the increase of reinforcement ratio can increase the repaired load. The closer the reinforced location is to the inner surface of the lining pipe, the higher the crack resistance of the structure and the lower the ultimate bearing capacity of the structure.
