城市綜合管廊供水管道彎管及其支墩體系力學分析
1，肖瑞2，崔萬麗2，陳建華3
HU Qun-fang,SUN Yan,XIAO Rui,et al.Mechanical Analysis of Bends and Supports of Water Supply Pipeline in Urban Utility Tunnel[J].China Water & Wastewater,2020,36(20):19-26.
城市綜合管廊供水管道彎管及其支墩體系力學分析
- Title:
- Mechanical Analysis of Bends and Supports of Water Supply Pipeline in Urban Utility Tunnel
- 作者:
- 胡群芳1,2，孫1，肖瑞2，崔萬麗2，陳建華3
- (1.同濟大學上海防災救災研究所，上海200092；2.同濟大學土木工程學院，上海200092；3.蕪湖新興鑄管有限責任公司，安徽蕪湖241000)
- 摘要:
- 近年來隨著我國城市市政管網建設、更新與改造，國家大力推動城市綜合管廊建設。相比于傳統的直埋式市政管線，管廊內主要采取吊架或支墩方式架空敷設各種管線，因此，管廊內大口徑有壓管道彎管連接區域，因輸送介質壓力方向改變會對管道產生附加的不平衡推力，從而影響其接頭與支墩受力狀態與安全。針對綜合管廊內敷設DN800大口徑球墨鑄鐵供水管道彎管及支墩受力問題，考慮2組9種不同角度連接工況下管道輸送水體—管體結構—支墩約束整體作用體系，利用流-固耦合分析方法，研究了彎管管道、支墩在不平衡推力作用下的結構內力分布與影響，并得到了綜合管廊彎管設計中管道與支墩設計內力控制截面。該研究工作可為城市綜合管道建設設計提供指導，并為管廊安全運營提供重要的技術支撐。
- Abstract:
- In recent years, the construction of the urban utility tunnel has been vigorously promoted with the construction, renewal and reconstruction of municipal pileline network in China. The water supply pipeline, as the most important part of the urban pipe network, has gradually changed from underground to overhead laying with supports or hangers in utility tunnels. Because water supply pipe is a pressure pipe with different angle connection, its water pressure will produce additional thrust force on the pipes bend. This paper analyzes the mechanical problems of DN800 ductile iron pipe bend, and the bearing capacity of buttresses is also investigated in urban utility tunnel. The thrust force of 2 groups with 9 working conditions of DN800 ductile iron pipe is stimulated by the fluid-solid coupling FEM method. The internal force control section for the pipe and buttress in the designed bend is obtained. The research work can provide a technical reference for the design and safe operation of the urban utility tunnel.
