[1]王倩,吳雪松,李偉,等.北排清河二廠污泥脫水工藝節能降耗優化運行策略[J].中國給水排水,2024,40(2):94-98.
WANGQian,WUXue-song,LIWei,et al.Optimized Operation Strategy for Energy Saving and Consumption Reduction of Sludge Dewatering Process in Qinghe Ⅱ Reclaimed Water Plant of Beijing Drainage Group[J].China Water & Wastewater,2024,40(2):94-98.點擊復制
北排清河二廠污泥脫水工藝節能降耗優化運行策略
中國給水排水[ISSN:1000-4062/CN:12-1073/TU] 卷: 第40卷 期數: 2024年第2期 頁碼: 94-98 欄目: 出版日期: 2024-01-17
Title:Optimized Operation Strategy for Energy Saving and Consumption Reduction of Sludge Dewatering Process in Qinghe Ⅱ Reclaimed Water Plant of Beijing Drainage Group
作者:王倩， 吳雪松， 李偉， 陶戰平， 李國權（北京城市排水集團有限責任公司，北京 100044）
Author(s):WANG Qian， WU Xue-song， LI Wei， TAO Zhan-ping， LI Guo-quan（Beijing Drainage Group Co. Ltd.， Beijing 100044， China）
關鍵詞:污泥處理; 污泥脫水; 節能降耗; 濃縮機; 預脫水機; 板框壓濾機
Keywords:sludge treatment; sludge dewatering; energy saving and consumption reduction; thickener; pre-dehydrator; plate and frame filter press
摘要:在“碳達峰、碳中和”的政策驅動下，為優化脫水工藝實現節能減排，2022年北排清河第二再生水廠污泥處理中心通過對濃縮機、預脫水機、板框壓濾機三個生產區域的設備處理量、運行數量和臺時進行調控，實現了脫水區域電單耗的顯著降低。通過提升濃縮機的進泥負荷、減少設備開機頻次，該區域電單耗下降17.52 kW·h/tDS；通過優化預脫水機開機頻次和螺旋輸送機運行，該區域電單耗下降3.48 kW·h/tDS；通過對板框區域采取分區運行、低壓進泥泵低頻率運行、無進料回流運行等措施，該區域電單耗同比下降約51.89 kW·h/tDS。采取以上工藝調控措施后，2022年脫水區域總電單耗為324.39 kW·h/tDS，較2021年下降17.9%，節電對應CO2減排量約1 440.09 t。
Abstract:Driven by the policy of “carbon peak and carbon neutrality”, in order to optimize the energy saving and emission reduction of dewatering process, the sludge treatment center of Qinghe Ⅱ reclaimed water plant of Beijing Drainage Group realized significantly reduction of unit power consumption in the dewatering area in 2022 by regulating the equipment treatment capacity, equipment operation quantity and unit hours in the three production areas of thickener, pre-dehydrator and plate and frame filter press. By increasing the sludge load of thickener and reducing the frequency of equipment start-up, the unit power consumption in this area decreased by 17.52 kW·h/tDS. By optimizing the start-up frequency of the pre-dehydrator and the operation of the screw conveyor, the unit power consumption in this area decreased by 3.48 kW·h/tDS. The unit power consumption in the plate and frame area decreased by 51.89 kW·h/tDS year on year by taking measures such as zoning operation, low frequency operation of low pressure sludge pump and no feed reflux operation. Through the above process control measures, the total unit power consumption in the dewatering area have decreased to 324.39 kW·h/tDS in 2022, 17.9% lower than that in 2021, and the power saving corresponds to about 1 440.09 t of CO2 emission reduction.
