[1]許勁,范準,呂秋穎,等.山地城市污泥水熱炭化產物特性研究[J].中國給水排水,2020,36(21):21-27.
XU Jin,FAN Zhun,L Qiu-ying,et al.Characteristics of Hydrothermal Carbonization Products of Municipal Sludge in Mountainous Cities[J].China Water & Wastewater,2020,36(21):21-27.點擊復制
山地城市污泥水熱炭化產物特性研究
中國給水排水[ISSN:1000-4062/CN:12-1073/TU] 卷: 第36卷 期數: 2020年第21期 頁碼: 21-27 欄目: 出版日期: 2020-11-01
Title:Characteristics of Hydrothermal Carbonization Products of Municipal Sludge in Mountainous Cities
作者:許勁1,2，范準1,2，呂秋穎1,2，唐琦1,2，李楊1,2，李遙瑤1,2，方俊華1,2(1.重慶大學環境與生態學院，重慶400045；2.重慶大學三峽庫區生態環境教育部重點實驗室，重慶400045)
Author(s):XU Jin1,2,FAN Zhun1,2,Lǚ Qiu-ying1,2,TANG Qi1,2,LI Yang1,2,LI Yao-yao1,2,FANG Jun-hua1,2(1. College of Environment and Ecology, Chongqing University, Chongqing 400045, China; 2. Key Laboratory of Three Reservoir Region’s Eco-Environment, Chongqing University, Chongqing 400045, China)
關鍵詞:山地城市; 污泥; 含砂量; 水熱炭化; 反應時間; 反應溫度
Keywords:mountainous city; sludge; sand content; hydrothermal carbonization; reaction time; reaction temperature
摘要:以山地城市污水處理廠未添加化學調理劑的濃縮污泥為原料，通過設置200、220、240、260 ℃這4個反應溫度和2、4、6 h這3個反應時間共12組實驗，探究反應溫度和反應時間對污泥水熱炭化固相和液相產物的影響。結果表明，隨著反應溫度和時間的增加，污泥水熱炭產率從69.32%（200 ℃-2 h）降至59.49%（260 ℃-6 h），同時水熱炭中的官能團O—H、C—H和C=C逐漸降解，H/C值和O/C值（物質的量之比）減小，水熱炭的脫羧和芳構化反應增強。整體而言，升高反應溫度比延長反應時間對污泥水熱炭化的影響更大。BMP（產甲烷潛力）實驗表明，隨著反應溫度的升高，液相產物中難降解有機物含量增加，而且其中的苯酚和呋喃衍生物等復雜有機物對厭氧反應具有抑制作用，累積甲烷產量隨之降低。隨著反應溫度和時間的增加，C含量呈上升趨勢，而H、O和N含量反之，水熱炭的高位熱值（HHV）、能量密度和能量產率均低于污泥原料。污泥的高含砂量對水熱炭的元素含量和熱值影響顯著，建議對污泥含砂量進行有效控制。
Abstract:Effects of reaction temperature and time on solid and liquid hydrothermal carbonization products of the concentrated sludge without adding chemical conditioner in a wastewater treatment plant of a mountainous city were investigated.Twelve groups of experiments were set up by setting four reaction temperatures (200 ℃, 220 ℃, 240 ℃ and 260 ℃) and three reaction times (2 h, 4 h and 6 h). With the increase of reaction temperature and time, the yield of sludge-based hydrothermal charcoal decreased from 69.32% (200 ℃ and 2 h) to 59.49% (260 ℃ and 6 h), the functional groups of O—H, C—H and C=C were gradually degraded, H/C value and O/C value decreased, and the decarboxylation and aromatization reactions of hydrothermal charcoal were enhanced. Overall, increasing reaction temperature had a greater impact on hydrothermal carbonization of sludge than extending reaction time. Biochemical methane potential (BMP) experiments indicated that the content of refractory organics in liquid products increased with the increase of reaction temperature,complex organics such as phenol and furan derivatives inhibited the anaerobic reaction, and the cumulative methane production decreased accordingly.With the increase of reaction temperature and time, the carbon content showed an upward trend, while the contents of hydrogen, oxygen, and nitrogen decreased, and the high heat value (HHV), energy density, and energy yield of hydrothermal charcoal were all lower than those of the raw sludge. The high sand content of sludge had a significant influence on the element content and HHV of hydrothermal charcoal. It was suggested to control the sand content of sludge effectively.
