非開挖修復技術在城市排水管道維護中的應用 周楊軍1，蔣仕蘭2，解銘1，趙祥1，孫子為1(1.中國城市規劃設計研究院，北京100037；2.臨沂市財政局，山東臨沂276000)
ZHOU Yang-jun,JIANG Shi-lan,XIE Ming,et al.Application of Trenchless Repair Technology in Urban Drainage Pipeline Maintenance[J].China Water & Wastewater,2020,36(20):58-62.
非開挖修復技術在城市排水管道維護中的應用
- Title:
- Application of Trenchless Repair Technology in Urban Drainage Pipeline Maintenance
- 關鍵詞:
- 非開挖修復; 排水管道; 臨時排水; 注漿
- 摘要:
- 對排水管道修復過程中常用的整體修復及局部修復等9種類型的工藝進行了綜述，分析了各類工藝的適用條件，并對非開挖修復過程中的臨時排水及注漿等輔助措施進行了介紹�？偨Y(jié)了非開挖修復過程中遇到的管道彎曲、變徑及暗井等特殊情況，并給出了解決方法及建議。最后結合南方某排水管道非開挖修復實際工程案例，介紹了非開挖修復工藝在城市排水管道中的具體應用情況。
- Abstract:
- Nine types of technologies commonly used in the repair of drainage pipeline, such as integral repair and localized repair, are summarized. The applicable conditions of various technologies are analyzed, and the auxiliary measures such as temporary drainage and grouting in the process of trenchless repair are introduced. The special cases of pipe bending, diameter changing and underground well encountered in the process of trenchless repair are summarized, also solutions and suggestion are given. Finally, based on a practical case of trenchless repair of a drainage pipeline in South China, the application of trenchless repair technology in urban drainage pipeline is introduced.
