[1]楊清,郭淑琴,陳偉楠.準Ⅳ類出水標準下天津咸陽路污水處理廠的遷建提標設計[J].中國給水排水,2021,37(12):88-92.
YANG Qing,GUO Shu-qin,CHEN Wei-nan.Design of Relocation of Tianjin Xianyanglu Sewage Treatment Plant Upgraded to Quasi-Ⅳ Standard[J].China Water & Wastewater,2021,37(12):88-92.點擊復制
準Ⅳ類出水標準下天津咸陽路污水處理廠的遷建提標設計
中國給水排水[ISSN:1000-4062/CN:12-1073/TU] 卷: 第37卷 期數: 2021年第12期 頁碼: 88-92 欄目: 出版日期: 2021-06-17
Title:Design of Relocation of Tianjin Xianyanglu Sewage Treatment Plant Upgraded to Quasi-Ⅳ Standard
作者:楊清,郭淑琴,陳偉楠(天津市政工程設計研究總院有限公司,天津300051)
Author(s):YANG Qing，GUO Shu-qin，CHEN Wei-nan(Tianjin Municipal Engineering Design & Research Institute Co. Ltd., Tianjin 300051， China)
關鍵詞:多級AO; 反硝化濾池; 臭氧催化氧化
Keywords:multi-stage AO; denitrification filter; ozone catalytic oxidation
摘要:天津咸陽路污水處理廠遷建提標一期工程處理規模為45×104 m3/d，再生水一期規模為5×104 m3/d，出水水質達到天津市地方標準《城鎮污水處理廠污染物排放標準》（DB 12/599—2015）中的A標準。污水處理主要工藝為：速沉池+多級AO反應池+二沉池+反硝化濾池+高效澄清池+V型濾池+臭氧催化氧化+紫外線消毒。經過近期的調試運行，污水處理廠出水各項指標均優于設計標準。運行過程中，當污水量有較大增長時，處理效果良好，體現出了良好的抗沖擊負荷能力；多級AO工藝在運行中表現出了較高的去除有機物和脫氮效率；高效沉淀池+V型濾池工藝對出水TP 和SS達標有很好的保障。后續可根據進水水質水量的實際情況靈活調整運行方式，在出水達標的情況下，減少運行費用。
Abstract:Treatment capacity of Tianjin Xianyanglu sewage treatment plant in the first phase relocation and upgrading project is 45×104 m3/d, and treatment capacity of the recycled water plant of the first phase is 5×104 m3/d, in which the effluent is required to meet class A limitations of Tianjin local Discharge Standard of Pollutants for Municipal Wastewater Treatment Plant (DB 12/599-2015). The main process of sewage treatment consists of rapid sedimentation tank, multi-stage AO reaction tank, secondary sedimentation tank, denitrification filter, high-efficiency sedimentation tank, V-shaped filter, ozone catalytic oxidation and UV disinfection. After the recent commissioning, effluent indices of the sewage treatment plant were better than those in the design standard. In the process of operation, when the amount of sewage increased greatly, good treatment performance was achieved, reflecting a good impact resistance load capacity of the process. The multi-stage AO process showed high organic matter removal and nitrogen removal efficiency in the operation. The high-efficiency sedimentation tank and V-shaped filter process could ensure that TP and SS in the effluent meet the discharge standard. The operation mode could be adjusted flexibly according to the actual situation of the water quality and quantity of the influent in the subsequent operation, so as to reduce the operation cost on the premise of the effluent water quality meeting the discharge standard.
相似文獻/References:
[1]劉圣譽,李彭,何義亮,等.基于人工神經網絡的反硝化濾池外碳源投加控制[J].中國給水排水,2020,36(7):19.
[2]隋克儉,李家駒,孫永利,等.南方城鎮污水極限氮磷去除工藝中試研究[J].中國給水排水,2020,36(7):97.
[3]劉楊華,陳波,劉麗,等.MSBR與BAF工藝用于市政污水處理工程提標擴建[J].中國給水排水,2020,36(14):109.
LIU Yang-hua,CHEN Bo,LIU Li,et al.Application of MSBR and BAF Process in Upgrading and Expansion Project of Municipal Wastewater Treatment Plant[J].China Water & Wastewater,2020,36(12):109.
[4]謝曉旺.多級AO與氧化溝工藝在污水廠擴建工程中應用對比[J].中國給水排水,2020,36(14):127.
XIE Xiao-wang.Application Comparison of Multi-stage AO and Oxidation Ditch Process in a WWTP Expansion Project[J].China Water & Wastewater,2020,36(12):127.
[5]栗文明,高敏,周軍,等.反硝化濾池污水處理工藝應用調研及設計要點[J].中國給水排水,2020,36(22):100.
LI Wen-ming,GAO Min,ZHOU Jun,et al.Application Survey and Design Points of the Denitrification Filter in Wastewater Treatment Process[J].China Water & Wastewater,2020,36(12):100.
[6]賀陽,袁紹春,蔣彬.新地方標準背景下污水處理項目的設計變更與實踐[J].中國給水排水,2021,37(8):78.
HE Yang,YUAN Shao-chun,JIANG Bin.Design Change and Practice of Sewage Treatment Project under the Background of New Local Standards[J].China Water & Wastewater,2021,37(12):78.
[7]李亮.MBBR在CAST工藝擴容提質工程中的應用[J].中國給水排水,2021,37(20):87.
LI Liang.Application of MBBR in CAST Process Expanding and Upgrading Project[J].China Water & Wastewater,2021,37(12):87.
[8]劉增軍,張開海,孫序營,等.多級AO用于高排放標準下低碳高氮生活污水處理[J].中國給水排水,2024,40(2):55.
LIUZeng-jun,ZHANGKai-hai,SUNXu-ying,et al.Application of Multi-stage AO in the Treatment of Low Carbon and High Nitrogen Domestic Sewage with High Discharge Standard[J].China Water & Wastewater,2024,40(12):55.
